HILL AIR FORCE BASE, Utah — An aerial view shows how the work stand is fitted around the C-130s wing and tail area. The black tubing above brings fresh-air heating and cooling to the work area, reducing ground clutter around the aircraft. (Air Force photo by Tom Whitney)


Depot maintenance

HILL AIR FORCE BASE, Utah — An aerial view shows how the work stand is fitted around the C-130s wing and tail area. The black tubing above brings fresh-air heating and cooling to the work area, reducing ground clutter around the aircraft. (Air Force photo by Tom Whitney)

Related Imagery
YUMA PROVING GROUNDS, Ariz. — A 10,000-pound payload dropped from a C-130 at 25,000 feet over Yuma Proving Grounds, Arizona, is guided by the Joint Precision Airdrop System. JPADS provides safe/accurate high altitude delivery to ground troops, while also protecting the aircraft, aircrew and the supplies. JPADS has a steerable canopy, an electro-mechanical steering actuator with an airborne guidance unit. The mobility community is calling JPADS the JDAM (Joint Direct Attack Munition) for logistics, because both are GPS-guided systems. JPADS delivers supplies and JDAM delivers guided munitions attacks. (Air Force courtesy photo)
ARNOLD AIR FORCE BASE, Tenn. — Nickolas Galyen, an engineer in Aerospace Testing Alliance’s Integrated Test and Evaluation department, aligns a calibration target during a series of tests to validate the use of stereo particle image velocimetry (PIV) in the 4-foot transonic wind tunnel at Arnold Engineering Development Center. Images of the precisely machined target are used to spatially calibrate particle images to measure three-dimensional velocity airflow fields. (Air Force photo by David Housch)
